| Model |
DEEPLE SL03 2024 135Pro Honor Edition |
DEEPLE SL03 2024 200Max 2nd Anniversary Black Gold Knight Edition |
DEEPLE SL03 2024 530Plus Pure Electric Edition |
DEEPLE SL03 2024 610Max Pure Electric Edition |
| Level |
Mid-size car |
Mid-size car |
Mid-size car |
Mid-size car |
| Energy type |
Extended range |
Extended range |
Pure electric |
Pure electric |
| Environmental protection standard |
National VI |
National VI |
—— |
—— |
| Time to market |
2024.02 |
2024.04 |
2024.02 |
2024.02 |
| WLTC pure electric cruising range (km) |
100 |
165 |
—— |
—— |
| CLTC pure electric cruising range (km) |
135 |
200 |
530 |
610 |
| Battery fast charging time (hours) |
0.5 |
0.5 |
0.58 |
0.41 |
| Battery fast charging capacity range (%) |
30-80 |
30-80 |
30-80 |
30-80 |
| Maximum power (kW) |
175 |
160 |
160 |
190 |
| Maximum torque (N·m) |
320 |
320 |
320 |
320 |
| Gearbox |
Electric vehicle single-speed gearbox |
Electric vehicle single-speed gearbox |
Electric vehicle single-speed gearbox |
Electric vehicle single-speed gearbox |
| Body structure |
5-door 5-seat hatchback |
5-door 5-seat hatchback |
5-door 5-seat hatchback |
5-door 5-seat hatchback |
| Engine |
1.5L 95 horsepower L4 |
1.5L 95 horsepower L4 |
Pure electric |
Pure electric |
| Electric motor (Ps) |
238 |
218 |
218 |
258 |
| Length*width*height (mm) |
4820*1890*1480 |
4820*1890*1480 |
4820*1890*1480 |
4820*1890*1480 |
| Official 0-100km/h acceleration (s |
7.2 |
7.5 |
6.9 |
6.2 |
| Maximum speed (km/h) |
170 |
170 |
170 |
170 |
| CLTC comprehensive fuel consumption (L/100km) |
1.11 |
0.7 |
—— |
—— |
| Minimum state of charge fuel consumption (L/100km) |
4.4 |
4.5 |
—— |
—— |
| Electric energy equivalent fuel consumption (L/100km) |
1.39 |
—— |
—— |
—— |
| Curb weight (kg) |
1780 |
1840 |
1935 |
1790 |
| Maximum full load weight (kg) |
2175 |
2235 |
2330 |
2185 |
| Wheelbase (mm) |
2900 |
2900 |
2900 |
2900 |
| Front track (mm) |
1620 |
1620 |
1620 |
1620 |
| Rear track (mm) |
1630 |
1630 |
1630 |
1630 |
| Approach angle (°) |
15 |
15 |
15 |
15 |
| Departure angle (°) |
20 |
20 |
20 |
20 |
| Body structure |
Hatchback |
Hatchback |
Hatchback |
Hatchback |
| Door opening method |
Sliding door |
Sliding door |
Sliding door |
Sliding door |
| Number of doors (pieces) |
5 |
5 |
5 |
5 |
| Number of seats (pieces) |
5 |
5 |
5 |
5 |
| Fuel tank capacity (L) |
45 |
45 |
—— |
—— |
| Front trunk capacity (L) |
—— |
—— |
70 |
70 |
| Rear trunk capacity (L) |
473 |
473 |
473-1487 |
473-1487 |
| Drag coefficient (Cd) |
0.23 |
0.23 |
0.23 |
0.23 |
| Engine model |
JL473QJ |
JL473QJ |
—— |
—— |
| Displacement (mL) |
1480 |
1480 |
—— |
—— |
| Displacement (L) |
1.5 |
1.5 |
—— |
—— |
| Intake form |
Naturally aspirated |
Naturally aspirated |
—— |
—— |
| Motor type |
Permanent magnet/synchronous |
Permanent magnet/synchronous |
Permanent magnet/synchronous |
Permanent magnet/synchronous |
| Total motor power (kW) |
175 |
160 |
160 |
190 |
| Total motor horsepower (Ps) |
238 |
218 |
218 |
258 |
| Total motor torque (N·m) |
320 |
320 |
320 |
320 |
| Maximum power of rear motor (kW) |
175 |
160 |
160 |
190 |
| Maximum torque of rear motor (N·m) |
320 |
320 |
320 |
320 |
| Number of drive motors |
Single motor, |
Single motor, |
Single motor, |
Single motor, |
| Motor layout |
Rear |
Rear |
Rear |
Rear |
| Battery type |
Lithium iron phosphate battery |
Lithium iron phosphate battery |
Lithium iron phosphate battery |
Ternary lithium battery |
| Battery cooling method |
Liquid cooling |
Liquid cooling |
Liquid cooling |
Liquid cooling |
| WLTC pure electric cruising range (km) |
100 |
165 |
—— |
—— |
| CLTC pure electric cruising range (km) |
135 |
200 |
530 |
610 |
| CLTC comprehensive cruising range (km) |
1140 |
1200 |
—— |
—— |
| Battery energy (kWh) |
18.99 |
28.39 |
58.89 |
66.8 |
| Power consumption per 100 kilometers (kWh/100km) |
13.1 |
13.1 |
12.8 |
12.4 |
| Fast charging function |
Support |
Support |
Support |
Support |
| Battery fast charging time (hours) |
0.5 |
0.5 |
0.58 |
0.41 |
| Battery fast charging capacity range (%) |
30-80 |
30-80 |
30-80 |
30-80 |
| Slow charging interface location |
Right rear side of the vehicle |
Right rear side of the vehicle |
Right rear side of the vehicle |
Right rear side of the vehicle |
| Fast charging interface location |
Right rear side of the vehicle |
Right rear side of the vehicle |
Right rear side of the vehicle |
Right rear side of the vehicle |
| External AC discharge power (kW) |
3.3 |
3.3 |
3.3 |
3.3 |
| Number of gears |
1 |
1 |
1 |
1 |
| Gearbox type |
Fixed gear ratio gearbox |
Fixed gear ratio gearbox |
Fixed gear ratio gearbox |
Fixed gear ratio gearbox |
| Drive mode |
Rear-mounted rear-wheel drive |
Rear-mounted rear-wheel drive |
Rear-mounted rear-wheel drive |
Rear-mounted rear-wheel drive |
| Parking brake type |
Electronic parking brake |
Electronic parking brake |
Electronic parking brake |
Electronic parking brake |
| Front tire specifications |
●225/55 R18 |
●245/45 R19 |
●245/45 R19 |
●245/45 R19 |
| Rear tire specifications |
●225/55 R18 |
●245/45 R19 |
●245/45 R19 |
●245/45 R19 |
| Spare tire specifications |
—— |
—— |
Tire repair tool |
Tire repair tool |
| Main / passenger airbags |
Main / auxiliary |
Main / auxiliary |
Main / auxiliary |
Main / auxiliary |
| Front / rear side airbags |
Front / rear none |
Front / rear none |
Front / rear none |
Front / rear none |
| Front / rear head airbags (air curtains) |
Front / rear |
Front / rear |
Front / rear |
Front / rear |
| ABS anti-lock brakes |
● |
● |
● |
● |
| Brake force distribution (EBD / CBC, etc.) |
● |
● |
● |
● |
| Brake assist (EBA / BAS / BA, etc.) |
● |
● |
● |
● |
| Traction control (ASR / TCS / TRC, etc.) |
● |
● |
● |
● |
| Vehicle stability control (ESC / ESP / DSC, etc.) |
● |
● |
● |
● |
