| Model |
MHERO 917 2024 Model Extended Range Extended Version |
MHERO 917 2024 Model Extended Range Jiaolong Armor |
| Level |
Large SUV |
Large SUV |
| Energy type |
Extended Range |
Extended Range |
| Environmental protection standard |
National VI |
National VI |
| Time to market |
—— |
2024.06 |
| WLTC pure electric cruising range (km) |
—— |
125 |
| Battery fast charging time (hours) |
0.61 |
0.62 |
| Battery fast charging capacity range (%) |
30-80 |
30-80 |
| Maximum power (kW) |
600 |
600 |
| Maximum torque (N·m) |
1050 |
1050 |
| Gearbox |
2-speed automatic |
2-speed automatic |
| Body structure |
5-door 5-seater SUV |
5-door 5-seater SUV |
| Electric motor (Ps) |
816 |
816 |
| Length*width*height (mm) |
5187*2080*1999 |
5052*2150*2059 |
| Official 0-100km/h acceleration (s) |
—— |
6.76 |
| Maximum speed (km/h) |
170 |
191 |
| Curb weight (kg) |
3270 |
—— |
| Maximum fully loaded weight (kg) |
3800 |
—— |
| Total weight of semi-trailer (kg) |
2500 |
—— |
| Wheelbase (mm) |
3150 |
2950 |
| Front track (mm) |
1755 |
1785 |
| Rear track (mm) |
1755 |
1785 |
| Minimum ground clearance when fully loaded (mm) |
221 |
—— |
| Minimum ground clearance (mm) |
—— |
257 |
| Approach angle (°) |
31 |
31 |
| Departure angle (°) |
31 |
34 |
| Longitudinal passing angle (°) |
19.7 |
21.9 |
| Maximum climbing grade (%) |
100 |
100 |
| Minimum turning radius (m) |
—— |
5.1 |
| Maximum wading depth (mm) |
900 |
900 |
| Number of doors (pieces) |
5 |
5 |
| Number of seats (pieces) |
5 |
5 |
| Fuel tank capacity (ㄩ) |
84 |
84 |
| Displacement (mL) |
1476 |
1476 |
| Displacement (L) |
1.5 |
1.5 |
| Intake form |
Turbocharged |
Turbocharged |
| Maximum horsepower (Ps) |
197 |
197 |
| Maximum power (kW) |
145 |
145 |
| Energy type |
Extended range |
Extended range |
| Fuel grade |
92 |
92 |
| Environmental protection standard |
National VI |
National VI |
| Front motor model |
TZ220XY01M |
TZ220XY01M |
| Rear motor model |
TZ220XY01M |
TZ220XY01M |
| Motor type |
Permanent magnet/synchronous |
Permanent magnet/synchronous |
| Total motor power (kw) |
600 |
600 |
| Total motor horsepower (Ps) |
816 |
816 |
| Total motor torque (N·m) |
1050 |
1050 |
| Number of drive motors |
Three motors |
Three motors |
| Motor layout |
Front + rear |
Front + rear |
| Battery cooling method |
Liquid cooling |
Liquid cooling |
| WLTC pure electric cruising range (km) |
—— |
125 |
| WLTC comprehensive cruising range (km) |
—— |
678 |
| Battery energy (kWh) |
65.8 |
65.8 |
| Fast charging function |
Support |
Support |
| Battery fast charging time (hours) |
0.61 |
0.62 |
| Battery fast charging capacity range (%) |
30-80 |
30-80 |
| External AC discharge power (kw) |
6 |
6 |
| Number of gears |
2 |
2 |
| Gearbox type |
Automatic transmission (AT) |
Automatic transmission (AT) |
| Drive mode |
Three-motor four-wheel drive |
Three-motor four-wheel drive |
| Four-wheel drive type |
Electric four-wheel drive |
Electric four-wheel drive |
| Front suspension type |
Double wishbone independent suspension |
Double wishbone independent suspension |
| Rear suspension type |
Double wishbone independent suspension |
Double wishbone independent suspension |
| Power-assisted type |
Electric power steering |
Electric power steering |
| Body structure |
Non-load bearing |
Non-load bearing |
| Front brake type |
Ventilated disc type |
Ventilated disc type |
| Rear brake type |
Ventilated disc type |
Ventilated disc type |
| Parking brake type |
Electronic parking brake |
Electronic parking brake |
| Front tire specifications |
275/65 R20 |
295/60 R20 |
| Rear tire specifications |
275/65 R20 |
295/60 R20 |
| Driver/passenger airbags |
—— |
Main/auxiliary |
| Front/rear side airbags |
—— |
Front/rear none |
| Front/rear head airbags (curtain airbags) |
—— |
Front/rear |
