| Model |
XPENG X9 2024 Model 610 Long Range Pro |
XPENG X9 2024 702 Long Range Pro |
XPENG X9 2024 702 Super Long Range Max |
XPENG X9 2024 640 4WD High Performance Max |
| Grade |
Mid-size MPV |
Mid-size MPV |
Mid-size MPV |
Mid-size MPV |
| Energy Type |
Pure Electric |
Pure Electric |
Pure Electric |
Pure Electric |
| Time to market |
2024.01 |
2024.01 |
2024.01 |
2024.01 |
| CLTC pure electric range (km) |
610 |
702 |
702 |
640 |
| Battery Fast Charge Time (hrs) |
0.33 |
0.33 |
0.33 |
0.33 |
| Battery fast charging range (%) |
10-80 |
10-80 |
10-80 |
10-80 |
| Maximum power (kW) |
235 |
235 |
235 |
370 |
| Maximum torque (N-m) |
450 |
450 |
450 |
450 |
| Body Structure |
5-door, 7-seat MPV |
5-door, 7-seat MPV |
5-door, 7-seat MPV |
5-door, 7-seat MPV |
| Motor(Ps) |
320 |
320 |
320 |
503 |
| Length*Width*Height(mm) |
5293*1988*1785 |
5293*1988*1785 |
5293*1988*1785 |
5293*1988*1785 |
| Official 0-100km/h Acceleration(s) |
7.7 |
7.7 |
7.7 |
5.7 |
| Maximum speed(km/h) |
200 |
200 |
200 |
200 |
| Electricity-equivalent fuel consumption (L/100km) |
1.83 |
1.84 |
1.84 |
2 |
| Total mass(kg) |
2560 |
2555 |
2555 |
2630 |
| Maximum loaded mass(kg) |
3125 |
3135 |
3135 |
3210 |
| Wheelbase(mm) |
3160 |
3160 |
3160 |
3160 |
| Front Wheelbase(mm) |
1679 |
1679 |
1679 |
1679 |
| Rear Wheelbase(mm) |
1683 |
1683 |
1683 |
1683 |
| Approach angle(°) |
14 |
14 |
14 |
14 |
| Departure Angle(°) |
15 |
15 |
15 |
15 |
| Body Structure |
MPV |
MPV |
MPV |
MPV |
| Door opening mode |
Flush door + side sliding door |
Flush door + side sliding door |
Flush door + side sliding door |
Flush door + side sliding door |
| Doors(pcs) |
5 |
5 |
5 |
5 |
| Seats(pcs) |
7 |
7 |
7 |
7 |
| Trunk volume(L) |
755-2554 |
755-2554 |
755-2554 |
755-2554 |
| Wind resistance(Cd) |
0.227 |
0.227 |
0.227 |
0.227 |
| Total motor power(kW) |
235 |
235 |
235 |
370 |
| Total Motor Horsepower(Ps) |
320 |
320 |
320 |
503 |
| Total motor torque (N-m) |
450 |
450 |
450 |
640 |
| Maximum power of front motor (kW) |
235 |
235 |
235 |
235 |
| Maximum torque of front motor (N-m) |
450 |
450 |
450 |
450 |
| Maximum power of rear motor (kW) |
—— |
—— |
—— |
135 |
| Max. torque of rear motor (N-m) |
—— |
—— |
—— |
190 |
| Number of drive motors |
Single Motor |
Single Motor |
Single Motor |
Dual Motor |
| Motor Layout |
Front |
Front |
Front |
Front + Rear |
| Battery type |
Lithium iron sulphate battery |
Ternary lithium battery |
Ternary lithium battery |
Ternary lithium battery |
| Battery cooling method |
Liquid-cooled |
Liquid-cooled |
Liquid-cooled |
Liquid-cooled |
| Battery Energy(kWh) |
84.5 |
101.5 |
101.5 |
101.5 |
| 100km power consumption(kwh/100km) |
16.2 |
16.3 |
16.3 |
17.7 |
| Fast charging function |
Support |
Support |
Support |
Support |
| Abbreviation |
Single Speed Gearbox for Electric Vehicles |
Single Speed Gearbox for Electric Vehicles |
Single Speed Gearbox for Electric Vehicles |
Single Speed Gearbox for Electric Vehicles |
| Number of gears |
1 |
1 |
1 |
1 |
| Transmission type |
Fixed Gear Ratio Transmission |
Fixed Gear Ratio Transmission |
Fixed Gear Ratio Transmission |
Fixed Gear Ratio Transmission |
| Chassis steering |
Dual Motor 4WD |
Dual Motor 4WD |
Dual Motor 4WD |
Dual Motor 4WD |
| Driving mode |
—— |
—— |
—— |
Electric four-wheel drive |
| Four-wheel drive |
Double Wishbone Independent Suspension |
Double Wishbone Independent Suspension |
Double Wishbone Independent Suspension |
Double Wishbone Independent Suspension |
| Front Suspension Type |
Multi-link independent suspension |
Multi-link independent suspension |
Multi-link independent suspension |
Multi-link independent suspension |
| Rear Suspension Type |
Electric Power Assist |
Electric Power Assist |
Electric Power Assist |
Electric Power Assist |
| Power Assist Type |
Load-carrying |
Load-carrying |
Load-carrying |
Load-carrying |
| Body Structure |
Ventilated disc |
Ventilated disc |
Ventilated disc |
Ventilated disc |
| Wheel Brake |
Ventilated disc |
Ventilated disc |
Ventilated disc |
Ventilated disc |
| Front Brake Type |
Electronic Parking |
Electronic Parking |
Electronic Parking |
Electronic Parking |
| Rear Brake Type |
235/55 R19 |
235/55 R19 |
235/55 R19 |
235/55 R19 |
| Parking Brake Type |
235/50 R20(Option 6000RMB) |
235/50 R20(Option 6000RMB) |
235/50 R20(Option 6000RMB) |
235/50 R20(Option 6000RMB) |
| Front Tyre Size |
235/55 R19 |
235/55 R19 |
235/55 R19 |
235/55 R19 |
| Rear Tyre Size |
235/50 R20(optional 6000RMB) |
235/50 R20(optional 6000RMB) |
235/50 R20(optional 6000RMB) |
235/50 R20(optional 6000RMB) |
| Assisted Driving Chips |
2 NVIDIA Orin-X |
2 NVIDIA Orin-X |
2 NVIDIA Orin-X |
2 NVIDIA Orin-X |
| Chip Total Computing Power |
508 TOPS |
508 TOPS |
508 TOPS |
508 TOPS |
| Lidar Brand |
—— |
—— |
RoboSense Sprint Polytron |
RoboSense Sprint Polytron |
| Number of LiDAR |
—— |
—— |
2 |
2 |
| Number of LIDAR lines |
—— |
—— |
126 Wire |
126 Wire |
| Assisted Driving System |
XPILOT |
XPILOT |
XNGP |
XNGP |
| Autopilot assisted road |
High Speed Sections |
High Speed Sections |
City Sections |
City Sections |
| High Speed Sections |
High Speed Sections |
